TOP254YN

     0 reviews  |  Write a review
Brand: Power Integrations
Product Code: TOP254YN
Availability: 1782
$0.00

We can ship to most of the country in the World.

Of course at a very low shipping cost, because we have a very good relationship for the discount.

We can ship by:

1. DHL

2. FEDEX

3. UPS

4. TNT

5. Normal Post

6. Any other shipping way you can choose.

Please Contact us for any questions about shipping:

sales@power-management-ic.com


Prepayment for new customer

1. Bank Transfer (Wire Transfer)

2. Paypal (You can use your credit card to pay by Paypal)

3. Western Union / Money Gram

If you have any questions about payment terms, you can feel free to contact us.

Mfg. Part NumberTOP254YN
ManufacturerPower Integrations
Product CategoryPMIC - AC DC Converters, Offline Switchers
DescriptionIC OFFLINE SWIT PROG OVP TO220
Datesheet Download Download
Internal Part NumberEIS-TOP254YN
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Product Training ModulesTOPSwitch® HX General Introduction
Reference Design LibraryDER-233: 6V @ 2.5A, 15W, 90 ~ 265VAC in
PCN Assembly/OriginAssembly Site Addition 15/May/2014
Standard Package50
Category Integrated Circuits (ICs)
FamilyPMIC - AC DC Converters, Offline Switchers
SeriesTOPSwitch®-HX
PackagingTube
Output IsolationIsolated
Internal Switch(s)Yes
Voltage - Breakdown700V
TopologyFlyback
Voltage - Start Up-
Voltage - Supply (Vcc/Vdd)-
Duty Cycle78%
Frequency - Switching66kHz, 132kHz
Power (Watts)62W
Fault ProtectionCurrent Limiting, Over Temperature, Over Voltage
Control Features-
Operating Temperature-40°C ~ 150°C (TJ)
Package / CaseTO-220-7 (Formed Leads), 6 Leads
Supplier Device PackageTO-220-7C
Mounting TypeThrough Hole
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)TOP254YN
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)TOP254YN
Related LinksTOP2, TOP254YN Datasheet, Power Integrations Distributor
